A 16 character x 2 line display used to indicate incoming calls in corridors, staff rooms, nursing stations, etc.
Includes an onboard sounder and buttons to accept, scroll through and manually divert calls.
Shows call type, call location and (depending on the device used to make the call) the User ID or name of the person calling.
Highest priority calls are shown first with a message saying how many calls are waiting.
Flash and sounder rates intensify to reflect the urgency of incoming calls.
Adjustable contrast and volume controls.
External sounder connection.

Power requirements	Nominal 24V DC (from Quantec Controller/Network).
Quiescent current	5mA (with back light off).
Indicators	2 line x 16 character backlit LCD display.
Controls	Accept (A); Scroll Up; Scroll Down. Adjust contrast; Adjust volume; Enable internal/external beeper.
Connections	Net +: Net -
Expansion connections	External sounder connection (current sink to the NET- line rated at 30 V, 30mA, 300 mW dissipation max.)
Onboard Sounder	Yes.
Onboard Infrared Receiver	No.
Product dimensions (mm)	146 W x 87 H x 35 D mm. Mount on a 35mm deep back box.
Construction & finish	Plastic.
IP Rating	IP40.
Weight	166g.
Operating conditions/temperature	-5ºC to +40ºC. Max relative humidity: 95%.

MPN

QT608C

Brand

QUANTEC

Product Code

QT608C

No reviews left yet

Write A Review

Free UK Delivery over £250

Returns Policy: The company operates a 14 day returns policy, products returned in an unopened / undamaged condition will be refunded.

Customer Reviews

QT608C Quantec Corridor Display

Name: QT608C Quantec Corridor Display
Brand: QUANTEC
SKU: QT608C
Price: 252.52 GBP
Availability: InStock

Product Code QT608C

A 16 character x 2 line display used to indicate incoming calls in corridors, staff rooms, nursing stations, etc.
