Description

58000-300APO - Apollo Discovery Carbon Monoxide Fire Detector, No Base

Discovery CO fire detectors contain a long-life electro-chemical carbon monoxide sensor which is tolerant of low levels of common vapours and household products. The sensing technology is fast, accurate and needs only very low power. The detection capabilities are enhanced by a rate-sensitive response. Fast rises in the carbon monoxide level are often associated with hot fires and the detector will respond earlier under these conditions. The analogue reply from the detector is rate limited to remove nuisance alarms resulting from short-term high levels caused by sources such as pipe smokers or gas flame ignition.

The Discovery Carbon Monoxide Detector is good at detecting deep-seated fires. Please note that CO detectors do not detect smoke particles or heat and are not universal replacements for smoke detectors.

Key Features

• Enhanced detection capability

• Ideal for smouldering fires

• Less susceptible to false alarms caused by steam than smoke detectors

• Five response modes

• Remote test feature

Specification

Applications                                  Hotels, Bedrooms, Hospitals, Medium to large buildings,                                                                                                                                         Offices, University campuses, Warehouses

Warranty                                         5 year

Analogue Value Nominal            25

Tolerance                                       +/- 2

Alarm Level Analogue Value      55

Chamber Type                              Chevron

Protocol Voltage                           5 to 9V peak to peak

Power-Up Surge Current            1mA

Maximum Power-Up Time          10 seconds

Status Indicator - Alarm               Red

Quiescent Current                        500μA

Supply Voltage                              17 to 28V dc

Terminal Functions L2                +L2 Loop in & out positive

Terminal Functions L1 In            -L1 in Loop in & out, double terminal

Terminal Functions +R                +R Remote indicator positive connection

Terminal Functions -R                 -R Remote indicator negative connection

Polarity                                            L1 & L2 are polarity sensitive

Alarm Current (At 24 Volts)         3.5mA

Humidity                                         15% to 90% (no condensation or icing)

Operating Temperature               0 to 50°C

IP Rating Value                             IP54

Storage Temperature                  10 to 30°C

Standards                                      BS EN 61000-6-3: 2007+A1: 2011                                                                                                                                                                                  BS EN 50130-4:2011+A1: 2014

Approvals                                       VNIIPO

Colour                                             White

Materials - Housing                     Polycarbonate

Materials - Terminals                  Nickel plated stainless steel

Product Height (w/o base)         42mm

Product Length                             42mm

Product Diameter                         100mm

Detection Principle                       Ambient carbon monoxide level

Details

• Model: 58000-300
• Shipping Weight: 105g
• For more information, please visit this product's webpage.
